Industrial X-ray imaging
Flat panel detectors are commonly used in automotive, aerospace, electronics, and other manufacturing industries for Non-Destructive Testing (NDT). They provide high-resolution images of the internal structure of materials, components, and various assemblies and are essential for detecting defects such as air pockets, cracks, voids, misaligned layers, missing components, and foreign objects.
Displaying 41 products (Industrial)
- Flat panel application
- Industrial, Battery, Electronics
- Technology
- IGZO
- Panel size (mm)
- 129 x 129
- Pixel matrix
- 1536 x 1536
- Pixel size
- 84 µm
- Scintillator
- CsI
- Interface
- 2.5 GigE
- Max frame rate
- 30-49 fps
- Max energy
- 160 kV
- Flat panel application
- Industrial, Electronics
- Technology
- a-Si
- Panel size (mm)
- 160 x 128
- Pixel matrix
- 1248 x 1024
- Pixel size
- 125 µm
- Scintillator
- CsI
- Interface
- 1 GigE
- Max frame rate
- 30-49 fps
- Max energy
- 160 kV
- Flat panel application
- Industrial, Electronics
- Technology
- a-Si
- Panel size (mm)
- 160 x 128
- Pixel matrix
- 1248 x 1024
- Pixel size
- 125 µm
- Scintillator
- GOS-Plus
- Interface
- 1 GigE
- Max frame rate
- 30-49 fps
- Max energy
- 160 kV
- Flat panel application
- Industrial, Battery, Electronics
- Technology
- IGZO
- Panel size (mm)
- 172 x 172
- Pixel matrix
- 2048 x 2048
- Pixel size
- 84 µm
- Scintillator
- CsI
- Interface
- 10 GigE
- Max frame rate
- 30-49 fps
- Max energy
- 160 kV
- Flat panel application
- Industrial, NDT
- Technology
- a-Si
- Panel size (mm)
- 204 x 204
- Pixel matrix
- 1024 x 1024
- Pixel size
- 200 µm
- Scintillator
- CsI
- Interface
- 1 GigE
- Max frame rate
- 30-49 fps
- Max energy
- 160 kV
- Flat panel application
- Industrial, NDT
- Technology
- a-Si
- Panel size (mm)
- 204 x 204
- Pixel matrix
- 1024 x 1024
- Pixel size
- 200 µm
- Scintillator
- GOS-Plus
- Interface
- 1 GigE
- Max frame rate
- 30-49 fps
- Max energy
- 160 kV
- Flat panel application
- Industrial, Battery, NDT
- Technology
- a-Si
- Panel size (mm)
- 243 x 307
- Pixel matrix
- 2432 x 3072
- Pixel size
- 100 µm
- Scintillator
- CsI
- Interface
- 2.5 GigE
- Max frame rate
- 15-23 fps
- Max energy
- 160 kV
- Flat panel application
- Industrial, Battery, NDT
- Technology
- a-Si
- Panel size (mm)
- 243 x 307
- Pixel matrix
- 2432 x 3072
- Pixel size
- 100 µm
- Scintillator
- CsI
- Interface
- 2.5 GigE
- Max frame rate
- 15-23 fps
- Max energy
- 350 kV
- Flat panel application
- Industrial, NDT
- Technology
- a-Si
- Panel size (mm)
- 243 x 307
- Pixel matrix
- 2432 x 3072
- Pixel size
- 100 µm
- Scintillator
- GOS-Plus
- Interface
- 2.5 GigE
- Max frame rate
- 15-23 fps
- Max energy
- 160 kV
- Flat panel application
- Industrial, NDT
- Technology
- a-Si
- Panel size (mm)
- 286 x 250
- Pixel matrix
- 2048 x 1792
- Pixel size
- 140 µm
- Scintillator
- CsI
- Interface
- 2.5 GigE
- Max frame rate
- 15-23 fps
- Max energy
- 160 kV
- Flat panel application
- Industrial, NDT
- Technology
- a-Si
- Panel size (mm)
- 286 x 250
- Pixel matrix
- 2048 x 1792
- Pixel size
- 140 µm
- Scintillator
- CsI
- Interface
- 2.5 GigE
- Max frame rate
- 15-23 fps
- Max energy
- 350 kV
- Flat panel application
- Industrial, NDT
- Technology
- a-Si
- Panel size (mm)
- 286 x 250
- Pixel matrix
- 2048 x 1792
- Pixel size
- 140 µm
- Scintillator
- CsI
- Interface
- 2.5 GigE
- Max frame rate
- 15-23 fps
- Max energy
- 450 kV
